HAFA-890H
FITLIFE
Performance Features:
1.Interational famous brand accessories, Mitsubishi PLC, Mitsubishi servo, Siemens panel, Omron meter meter
2. Photoelectric detection of paper tube core,detection of aluminum foil raw materials, labeling detection
3.Short standard closing, more cost saving
4.5 meters a roll, 25 rolls a minute
5. Warranty cycle up to 4 years
6.The most cost-effective rewinder
The machine has three cursor recognition, automatic paper tube, automatic material cutting, automatic labeling.
After the aluminum foil sealing technology is upgraded, it can be completed by short standard.
Warranty period up to 4 years, do not worry about after-sales problems.
4 shafts
Short Label
Mitsubishi PLC
Technical Parameters:
o Thickness of raw material:0.008mm-0.04mm
o Raw material width:100-500mm
o Maximum unwinding diameter:Φ600mm
o Inner diameter of raw material roll core: Φ76mm or Φ152mm
o Inner diameter of finished product roll core:Φ25mm,Φ30mm and Φ38mm
o Cutting length of roll:3m-300m
o Production efficiency:Calculation with 5m of roll cutting length, 5-30 rolls/min
o Magnetic powder brake: 25N.Mo Magnetic powder clutch: 25N.M
o Complete machine power:6.5KW
o Overall dimension:4,000mm×1,400mm×1,820mm
o Complete machine weight:About 1,900kg
Performance Features:
1.Interational famous brand accessories, Mitsubishi PLC, Mitsubishi servo, Siemens panel, Omron meter meter
2. Photoelectric detection of paper tube core,detection of aluminum foil raw materials, labeling detection
3.Short standard closing, more cost saving
4.5 meters a roll, 25 rolls a minute
5. Warranty cycle up to 4 years
6.The most cost-effective rewinder
The machine has three cursor recognition, automatic paper tube, automatic material cutting, automatic labeling.
After the aluminum foil sealing technology is upgraded, it can be completed by short standard.
Warranty period up to 4 years, do not worry about after-sales problems.
4 shafts
Short Label
Mitsubishi PLC
Technical Parameters:
o Thickness of raw material:0.008mm-0.04mm
o Raw material width:100-500mm
o Maximum unwinding diameter:Φ600mm
o Inner diameter of raw material roll core: Φ76mm or Φ152mm
o Inner diameter of finished product roll core:Φ25mm,Φ30mm and Φ38mm
o Cutting length of roll:3m-300m
o Production efficiency:Calculation with 5m of roll cutting length, 5-30 rolls/min
o Magnetic powder brake: 25N.Mo Magnetic powder clutch: 25N.M
o Complete machine power:6.5KW
o Overall dimension:4,000mm×1,400mm×1,820mm
o Complete machine weight:About 1,900kg
